ST Standard Fiber Optic Patchcord Manufacture ST Type Fiber Patch Cord VPCST manufacturer from China NINGBO MAX COMMUNICATIONS EQUIPMENT CO.,LTD

ST Standard Fiber Optic Patchcord Manufacture ST Type Fiber Patch Cord

Price:	2.0 USD
Payment Terms:	T/T,WU,Paypal,Money Gram
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: VPCST

Production Capacity: 100000PCS /Month

Delivery Date: as the order quantity

Type: ST

Repeatability(dB): ≤ 0.20

Insert Loss(dB): ≤ 0.20

Industry Standard: ROHS.IEC.GR-326

Storage Temperature(℃): -40℃-+85℃

Means of Transport: Ocean,Land,Air

Packing: Carton or upon on requests.

Brand Name: VTOM

Polish Type: PC/UPC/APC

Exchangeability(dB): ≤ 0.20

Resistance(≥1000)(dB): ≤ 0.20

Operating Temperature(℃): -40℃-+85℃

Place of Origin: ZheJiang,China(mainland)

Insert Loss:SM/PC(≤0.30dB),SM/UPC(≤0.30dB),SM/APC(≤0.30dB),MM(≤0.20dB)
Return Loss:SM/PC(≥45dB),SM/UPC(≥50dB),SM/APC(≥60dB),

ST Standard Fiber Optic Patchcord,welcom to our website to see fiber optic patch cord.We have SC,LC,FC,ST,MU,MPO.E2000 and Armored Fiber Optic Patch Cord for your good choice.

Because of the high quality and best price, many of our products are already sold in Russia, France, Germany, Spain, Italy, The USA, Canada, Brazil and so on.

Picture of ST Standard Fiber Optic Patchcord

Specification of ST Standard Fiber Optic Patchcord

Type	SM			MM
Type	PC	UPC	APC	/
Insert Loss	≤0.30dB	≤0.30dB	≤0.30dB	≤0.20dB
Return Loss	≥-45dB	≥-50dB	≥-60dB	/
Repeatability	≤0.2dB
Exchangeability	≤0.2dB
Resistance(≥1000 times)	≤0.2dB
Industry Standard	ROHS,IEC , GR-326
Operating Temperature	-40℃～+85℃
Storage Temperature	-40℃～+85℃

Application

Telecommunication
Test equipment
Fiber to the home
LANS WANS
CATV
Fiber optic sensors

Features

Low insert loss
High return loss
Compact andante-pull design ,corrosion resistant body
High reliability
Simplex and duplex for standard
Easy installation
Comply with Telcordia GR-326-CORE,ICE Standard

Order Information

VPCST----------------XX-------------XX-----------X---------X-------XXXX
	Model	Fiber type	Fiber diameter	Fiber Length	Connector Type
V=Vtom	SM=Singlemode	SX=Simplex	Φ0.9	1.0M	FC/UPC
PC=Patchcord	MM=Multimode 50/125um	DX=Duplex	Φ02.0	1.5M	FC/APC
ST=ST Type	MM=Multimode 62.5/125um	4 cores	Φ3.0	2.0M
		6cores	…	3.0M
		8cores		5.0M
		12cores		10.0M
		…		…

Equipments

Export to the following countries

Advantages:

We can delivery the samples for your test free of charge
Our products are all guaranteed,you will have no worry to use.
We will delivery the order strictly as the order confirmed
We can provide one-stop service for your shopping more convenient
Our products have high quality and best price list

Noted

Dear friend,thank you very much for your attention to ST Standard Fiber Optic Patchcord. If you have any need please contact with Susan at any time, I will do my best to reply you as soon as possible.
