SC Fiber Adapters Fiber Optical Adaptors SC Type

Price:	0.1 USD
Payment Terms:	T/T,WU,Paypal,Money Gram
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: VSASC

Production Capacity: 100000PCS /Month

Delivery Date: as the order quantity

Type: SC

Insetion Loss(dB): ≤ 0.20

Temperature Stability(dB): ≤ 0.30

Storage Temperature(℃): -40℃-+85℃

Exchange ability(dB): ≤ 0.20

Means of Transport: Ocean,Land,Air

Packing: 25pcs/plastic box

Brand Name: VTOM

Polish Type: PC/APC

Mating Durability(dB): ≤ 0.20

Operating Temperature(℃): -40℃-+85℃

Withdrawal Force(g/f): 200-600

Repeatability(dB): ≤ 0.10

1.Place of Origin:ZheJiang,China(mainland)
2.Sleeves Material:Ceramic
3.Anti-flaming:UL94-V0
4.Heat Distortion Temperature(℃):120

SC Fiber Adapters Fiber Optical Adaptors SC Type,we have single mode and multi mode for your choice,and we also supply simplex,duplex,UPC and APC .

Because of the high quality and best price, many of our products are already sold in Russia, France, Germany, Spain, Italy, The USA, Canada, Brazil and so on.

Picture of SC Fiber Adapters Duplex Fiber Optical Adaptors SC Type
Specification

Polish Type	Insertion Loss(dB)	Mating Durability(dB)	Temperature Stability(dB)	Operating Temperature(ºC)	Storage Temperature(ºC)	Withdrawal Force(g/f)
PC/APC	≤0.20	≤0.20	≤0.30	-40ºC～+85ºC	-40ºC～+85ºC	200-600
	Exchangeability(dB)	Repeatability(dB)	Sleeves Material	Anti-flaming	Heat Distortion Temperature(ºC)	Pull in& out Times
	≤0.20	≤0.10	Ceramic	UL94-V0	120	≥500

Application

Optical fiber transmission system

CATV

CATV Network

Optical fiber access network

LAN

Optical fiber test instruments

Fiber Distribution Frame,Fiber optic wall-mount & rack-mount cabinets

Features

Excellent changeability and directivity

100% optic test (insertion loss)

Ceramic and phosphor bronze sleeve tube optional

Accurate external size

High reliability

Individual package available

Order information

VSASC-------------------XX---------------------XX---------------XXX
	Model	Fiber Adaptor Type	Polish Type
V=Vtom	SM=Singlemode	SX=Simplex	UPC
SASC=Standard	MM=Multimode	DX=Duplex	APC
adaptor SC Type		4 cores

Export to the following countries

Advantages:

1)Our factory located in Ningbo which is one of the largest ports in China.

2)Most of our engineers and workers is dealing with the fiber optic adaptor many years.

3)Many of our items have large stock for your fast shippment

4)Many of our products assembling by automatic machine,,so that we not only can increase production,control the quality very well,but also we can lower the cost and offer our best competitive price to our customers.

5)All of our staff study advanced science and technology every month.

Promise to customers

1)We can delivery the samples for your test free of charge

2)Our products are all guaranteed,you will have no worry to use.

3)We will delivery the order strictly as the order confirmed!

4)Our products have high quality and best price list

Noted

Dear friend,thank you very much for your attention to Fiber Optic Adaptor SC type female to female. If you have any need please contact with Susan at any time, I will do my best to reply you as soon as possible.
